Scott Speedster 20 Shimano Tiagra 10-Speed - 2025
Please see photos for detailed specifications.
We ship within the USA and International.
For additional information or photos, please email lascolinas@playtri.com or call us at (214) 484-9788
The SCOTT Speedster 20 is a light, agile, and cost-efficient alloy road bike. With fully integrated cables, not only will this bike ride well, but it will most definitely look the part!
Key Features
- Speedster Disc Carbon Fork
- Speedster Disc Alloy Frame
- Shimano Tiagra Disc 20 Speed
- Syncros Race 24 Disc Rims
- Schwalbe Lugano Tires
Specifications
-
Frame: Speedster Disc / 6061 D.Butted Alloy Endurance geometry / int. cable routing Syncros fender kit ready
-
Fork: Speedster HMF Disc 1 1/4"-1 1/2" Eccentric Carbon steerer
-
Rear Derailleur: Shimano Tiagra RD-4700-GS 10-Speed
-
Front Derailleur: Shimano Tiagra FD-4700
-
Shifters: Shimano Tiagra ST-4700 Dual control 2x10-Speed
-
Crankset: Shimano Tiagra FC-R4700 50/34
-
Bottom Bracket: Shimano BB-RS500-PB
-
Chain: KMC X10
-
Cassette: Shimano CS-HG500 10-Speed 11-32
-
Brakes: Shimano BR-RS305 Black Mechanical Disc
-
Rotors: Shimano SM-RT64 rotor 160/F and 160/R
-
Handlebar: Syncros Creston 2.0 Compact 31.8mm
-
Stem: Syncros RR2.5 1 1/4" / four Bolt 31.8mm
-
Seatpost: Syncros RR2.5 27.2/350mm
-
Saddle: Syncros Tofino Regular 2.5
-
Headset: Acros AIF-1133
-
Hubs: Formula Team II CL Disc 28 H
-
Spokes: Black 2mm
-
Rims: Syncros Race 24 Disc 28 Front / 28 Rear
-
Tires: Schwalbe Lugano 700x32C
-
Approximate Weight: 22.93lbs (10.4kg)
-
Maximum System Weight: 264.55lbs (120kg) The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Geometry
| XXS/47 | XS/49 | S/52 | M/54 | L/56 | XL/58 | XXL/61 | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | head tube angle | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° | |||||||||
| B | head tube length | 93.0 mm | 103.0 mm | 123.0 mm | 143.0 mm | 163.0 mm | 183.0 mm | 203.0 mm | |||||||||
| C | top tube horizontal | 515.0 mm | 525.0 mm | 540.0 mm | 554.0 mm | 569.0 mm | 583.0 mm | 596.0 mm | |||||||||
| D | standover height | 735.0 mm | 754.0 mm | 780.0 mm | 800.0 mm | 820.0 mm | 840.0 mm | 864.0 mm | |||||||||
| E | BB offset | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | -70.0 mm | |||||||||
| F | BB height | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | 275.3 mm | |||||||||
| G | wheel base | 1,001.5 mm | 1,007.9 mm | 1,010.0 mm | 1,015.8 mm | 1,023.3 mm | 1,030.3 mm | 1,043.0 mm | |||||||||
| H | BB center to toptube center | 430.0 mm | 450.0 mm | 480.0 mm | 500.0 mm | 520.0 mm | 540.0 mm | 570.0 mm | |||||||||
| I | BB center to top of seattube | 470.0 mm | 490.0 mm | 520.0 mm | 540.0 mm | 560.0 mm | 580.0 mm | 610.0 mm | |||||||||
| J | seat angle | 75.0 ° | 75.0 ° | 74.5 ° | 74.0 ° | 73.5 ° | 73.1 ° | 73.0 ° | |||||||||
| K | chainstay | 425.0 mm | 425.0 mm | 425.0 mm | 425.0 mm | 427.0 mm | 427.0 mm | 427.0 mm | |||||||||
| L | reach | 376.0 mm | 383.0 mm | 387.0 mm | 391.0 mm | 385.0 mm | 399.0 mm | 406.0 mm | |||||||||
| M | stack | 517.8 mm | 529.1 mm | 551.6 mm | 572.4 mm | 593.3 mm | 613.6 mm | 632.7 mm | |||||||||
| N | stem length | 83.0 mm | 83.0 mm | 93.0 mm | 103.0 mm | 103.0 mm | 113.0 mm | 113.0 mm | |||||||||
